Three simple multi-LLM workflow patterns that trade cost or latency for potentially improved task performance. Sample implementations meant to demonstrate core concepts — not production code.

Published by Anthropic, December 19, 2024.

Content

Overview

Pattern	Description	Trade-off
Prompt chaining	Decomposes a task into sequential subtasks; each step builds on previous results	Higher latency; better accuracy per step
Parallelization	Distributes independent subtasks across multiple LLM calls concurrently	Higher cost; faster wall-clock time
Routing	Dynamically selects a specialized LLM path based on input characteristics	Extra classification call; specialized handling

Core implementations

from concurrent.futures import ThreadPoolExecutor

from util import extract_xml, llm_call


def chain(input: str, prompts: list[str]) -> str:
    """Chain multiple LLM calls sequentially, passing results between steps."""
    result = input
    for i, prompt in enumerate(prompts, 1):
        print(f"\nStep {i}:")
        result = llm_call(f"{prompt}\nInput: {result}")
        print(result)
    return result


def parallel(prompt: str, inputs: list[str], n_workers: int = 3) -> list[str]:
    """Process multiple inputs concurrently with the same prompt."""
    with ThreadPoolExecutor(max_workers=n_workers) as executor:
        futures = [executor.submit(llm_call, f"{prompt}\nInput: {x}") for x in inputs]
        return [f.result() for f in futures]


def route(input: str, routes: dict[str, str]) -> str:
    """Route input to specialized prompt using content classification."""
    print(f"\nAvailable routes: {list(routes.keys())}")

    selector_prompt = f"""
Analyze the input and select the most appropriate support team from these options: {list(routes.keys())}

First explain your reasoning, then provide your selection in this XML format:

<reasoning>
Brief explanation of why this ticket should be routed to a specific team.
Consider key terms, user intent, and urgency level.
</reasoning>

<selection>
The chosen team name
</selection>

Input: {input}""".strip()

    route_response = llm_call(selector_prompt)
    reasoning = extract_xml(route_response, "reasoning")
    route_key = extract_xml(route_response, "selection").strip().lower()

    print("Routing Analysis:")
    print(reasoning)
    print(f"\nSelected route: {route_key}")

    selected_prompt = routes[route_key]
    return llm_call(f"{selected_prompt}\nInput: {input}")

Example 1: Chain — structured data extraction and formatting

Each step progressively transforms raw text into a formatted markdown table.

data_processing_steps = [
    """Extract only the numerical values and their associated metrics from the text.
Format each as 'value: metric' on a new line.""",
    """Convert all numerical values to percentages where possible.
If not a percentage or points, convert to decimal (e.g., 92 points -> 92%).""",
    """Sort all lines in descending order by numerical value.
Keep the format 'value: metric' on each line.""",
    """Format the sorted data as a markdown table with columns:
| Metric | Value |
|:--|--:|
| Customer Satisfaction | 92% |""",
]

report = """
Q3 Performance Summary:
Our customer satisfaction score rose to 92 points this quarter.
Revenue grew by 45% compared to last year.
Market share is now at 23% in our primary market.
Customer churn decreased to 5% from 8%.
New user acquisition cost is $43 per user.
Product adoption rate increased to 78%.
Employee satisfaction is at 87 points.
Operating margin improved to 34%.
"""

formatted_result = chain(report, data_processing_steps)

Final output (Step 4):

Metric	Value
Customer Satisfaction	92%
Employee Satisfaction	87%
Product Adoption Rate	78%
Revenue Growth	45%
User Acquisition Cost	43.0
Operating Margin	34%
Market Share	23%
Previous Customer Churn	8%
Customer Churn	5%

Example 2: Parallelization — stakeholder impact analysis

Process impact analysis for multiple stakeholder groups concurrently with the same prompt.

stakeholders = [
    """Customers:\n - Price sensitive\n - Want better tech\n - Environmental concerns""",
    """Employees:\n - Job security worries\n - Need new skills\n - Want clear direction""",
    """Investors:\n - Expect growth\n - Want cost control\n - Risk concerns""",
    """Suppliers:\n - Capacity constraints\n - Price pressures\n - Tech transitions""",
]

impact_results = parallel(
    """Analyze how market changes will impact this stakeholder group.
Provide specific impacts and recommended actions.
Format with clear sections and priorities.""",
    stakeholders,
)

Each stakeholder group receives a structured analysis with prioritized impacts, recommended actions, timelines, and success metrics. The notebook runs all four analyses in parallel via ThreadPoolExecutor.

Example 3: Route — customer support ticket handling

Route support tickets to specialized teams (billing, technical, account, product) based on content analysis with chain-of-thought classification.

support_routes = {
    "billing": """You are a billing support specialist...""",
    "technical": """You are a technical support engineer...""",
    "account": """You are an account security specialist...""",
    "product": """You are a product specialist...""",
}

tickets = [
    "Subject: Can't access my account\nMessage: ... invalid password ...",
    "Subject: Unexpected charge on my card\nMessage: ... $49.99 vs $29.99 ...",
    "Subject: How to export data?\nMessage: ... bulk export to Excel ...",
]

for ticket in tickets:
    response = route(ticket, support_routes)

Routing results from the cookbook:

Ticket	Selected route	Rationale
Password/login error (urgent)	account	Account access and authentication issue
Unexpected $49.99 charge	billing	Pricing plan discrepancy and payment question
Bulk export to Excel how-to	technical	Product functionality / step-by-step instructions

The routing step uses XML-tagged <reasoning> and <selection> output, parsed via extract_xml, before invoking the matched specialist prompt.

Key Takeaways

• Three foundational workflow patterns — chain, parallel, and route — cover most multi-LLM orchestration needs with minimal code.
• Prompt chaining works when a task decomposes cleanly into fixed sequential steps (e.g., extract → normalize → sort → format).
• Parallelization suits independent subtasks that share a prompt but differ in input (e.g., per-stakeholder analysis); use ThreadPoolExecutor for concurrent LLM calls.
• Routing adds a classification step with explicit reasoning before dispatching to specialized prompts — useful for support triage and domain-specific handlers.
• These are cookbook demos, not production patterns; pair with the broader guidance in Building Effective Agents for when to use workflows vs autonomous agents.
